3 Storey Building | 3 Story Tent





Triple Decker Structure

The 3 story tent structure adopts an advanced modular design, which can be flexibly combined to achieve efficient utilization of multi-layer space. It adopts a high-quality aluminum alloy frame, which is structurally stable, safe and reliable, ensuring safety during use. Meanwhile, its modular design facilitates quick assembly and disassembly, making the construction process simple and efficient. Whether it’s short-term activities or long-term projects, our 3 storey building structure can provide you with an ideal solution featuring high capacity, high flexibility, and high security, maximizing the use of limited space.

INQUIRY ONLINE

Features
Specifications
Why Choose Us
Applications
Cases
FAQ

Features

Robust Aluminum Alloy Frame

Built with extruded 6061/T6 aluminum, our 3 storey building frame offers exceptional strength and a lifespan of 15~20 years.

Fully Customized

Widths range from 10 m to 30 m and can be extended in 5 m bays. The 3 storey building structure provides three floors, each 3.3–4 m tall, reaching up to 12 m in total eave height. Floor heights and spans are tailored to your needs.

Flexible Interior Options

You can choose from internal or external staircases, balconies, mezzanine levels, glass or PVC walls, and flooring systems including cassette or wood.

Efficient Space Utilization

Expand vertically instead of outward — ideal for venues with limited ground area.

Weather-Resistant & Durable

High-quality PVC fabric is waterproof, UV-resistant, and flame-retardant, ensuring long-lasting performance in all climates.

Versatile Layouts

The 3 story tent is perfect for VIP lounges, exhibitions, viewing decks, and multi-purpose levels with endless design possibilities.

Specifications

Item	Specification
Clear Span Width	A Frame Design / Flat Roof Design:10m/20 m/25 m/30 m.
Side Height (First Floor)	4 m
Side Height (Second Floor)	4 m
Eave Height	12 m
Ridge Height	A Frame Design:13.625m. Flat Frame Design:12.615 m.
Bay Spacing	5 m
Wind Loading	115 MPH
Floor Loading Capacity	200 kg/m²~500 kg/m²

Item	Specification
Roof Pitch	A Frame Design:18° Flat Roof Design:7°
Main Profile	300 x 120 x 5 x 7 mm, 350 x 120 x 5 x 7 mm
Roof Options	Single-layer Roof Fabric, Double-layer Inflatable Roof Fabric
Roof Fixing	TR20 Tensioning Screw Rod
Eave Connection	Hot-dip Galvanized Twin Steel Plate
Framework Material	Hard Pressed Extruded Aluminium Alloy 6061/T6
Cover Material	PVC-coated Polyester Textile, Opaque, Waterproof, 850 g/m². Flame Retardant

Detailed Inquiries, Please Contact Sales Manager.

KENTEN Triple Decker Structure VS Regular Triple Decker Structure

	KENTEN Structures	Others
Aluminum	6061 T6 / 6082 T6	6063 T5 / 6005 T5
PVC Fire Retardant	B1,M2	B2
Wind Resistance	Up to 120 km/h	Up to 80 km/h
Lifespan	20 Years (Frame)	10 Years (Frame)

Why Choose KENTEN Triple Decker Structure?

Maximize Space

Three full levels of usable area without increasing your footprint — perfect for city venues, racetracks, or trade shows.

Prestige & Visual Impact

A towering, multi-level structure instantly elevates your event and brand image, offering a premium, building-like presence.

Functional Zones

Ground Floor: Registration, dining, product showcases

Second Floor: Meetings, lounges, hospitality spaces

Top Floor: Executive suites, media booths, VIP experiences

Engineered for Reliability

Withstands strong wind and snow loads.

Fast Installation & Reusable

Set up in days. Modular design, reusable, relocatable, suitable for a variety of activities.

Cost-Effective Alternative

Get the function of a permanent building at a fraction of the cost.

Applications

High-end Exhibitions & Trade Shows

F1 and Motorsport Events

Major Sports Tournaments

VIP Hospitality & Media Centers at Concerts and Festivals

Video

Our Cases

Every solution we deliver is precisely matched to the scenario and requirements.

Formula 1 Miami Grand Prix

19th Asian Games – Hangzhou 2023

2022 Beijing Winter Olympic Games

2008 Beijing Olympic Games

Formula 1 Montreal Grand Prix

2025 Doha Photography Exhibition

Formula 1 Canadian Grand Prix

American Customer Customized Atrium Tent For Wedding

Customized Atrium Wedding Tent

Customized Warehouse Project For Chilean Customers

Customized Warehouse Project for Chilean Client

Toyota New Car Launch

FAQs About Our Clear Span Building Structure

Frequently Asked Questions About Triple Decker Structure

Q1: What is a 3 story tent?

A: A modular, clear-span structure with three functional floors — designed for premium events, exhibitions, sports hospitality, and temporary architecture.

Q2: What size options are available?

A: Widths: 10–30 m; Length: unlimited (extendable in 5 m bays); Floor height: 3.3–4 m each.

What materials are used?

Frame: 6061-T6 aluminum alloy

Roof & Walls: PVC-coated polyester, UV-resistant, waterproof, fire-retardant (B1/NFPA 701)

Optional: Glass walls

Q3: What customization options are offered?

A: Glass or PVC sidewalls

Internal/external staircases

Balconies & terraces

Flooring systems (cassette, wood, carpet)

HVAC, lighting, branding panels, signage

Q4: Can it be relocated or reused?

A:Yes. Fully modular and demountable — ideal for traveling events or seasonal use.

Q5:Can it be used permanently?

A: Yes, with proper anchoring and fit-outs, the modular building can function as a semi-permanent structure.

Q6: Is it suitable for extreme weather?

A: Yes. Engineered for wind speeds up to 100 km/h and heavy snow loads.

Q7: Do you provide design support?

A: Absolutely. We offer 3D layouts, engineering drawings, and full interior planning.
