Dome Tent





The dome tent adopts a geometric dome structure combined with a clear span structure design. The intersecting poles create a stable triangular mechanical system that ensures high strength and excellent wind resistance, while keeping the interior completely unobstructed to maximize usable space. Whether used as a camping tent, event display space, temporary storage, or outdoor reception area, the interior layout can be flexibly adjusted. In addition, its modular design makes it highly versatile, allowing users to expand or reconfigure the tent according to their specific needs.

INQUIRY ONLINE

Features
Specifications
Why Choose Us
Applications
Cases
FAQ

Features

Distinctive Aesthetics

The dome tent features a unique semi-spherical or oval silhouette that delivers a bold, modern aesthetic, making it a true focal point for any event or venue.

Built for All-Weather Reliability

The frame uses heavy-duty Q235 steel for outstanding strength and stability. The premium PVC tarpaulin (850g/m²) is waterproof, UV-resistant, flame-retardant, and exceptionally long-lasting—ensuring the dome tent performs reliably in a wide range of outdoor environments.

Fast & Efficient Installation

Factory-prefabricated components allow for quick on-site assembly—medium-sized dome tents can be set up by just a few people in a short time.

Modular & Expandable

The modular design makes it easy to connect multiple domes, expand interior space, or add custom platform systems for extended functionality.

Fully Customization

Choose your ideal size, fabric color, patterns, and accessories—from glass walls and doors to lighting, flooring, and climate control—to design and configure your outdoor dome tent exactly as you envision it.

Multi-Purpose Applications

Thanks to its spacious, clear span interior and premium finish, the dome tent is ideal for high-end events, VIP lounges, exhibitions, product launches, private parties, and more.

Specifications

Diameter	Ridge Height	Structural Layers	Pipe Diameter	Base Plate	Area
10 M	5 M	6	Ø32 * 1.5 mm	36	78.5 m²
15 M	7.5 M	6	Ø32 * 1.5 mm	36	176.625 m²
20 M	10 M	7	Ø42 * 2.0 mm	42	314 m²
25 M	12.5 M	9	Ø42 * 2.0 mm	54	490.625 m²
30 M	15 M	11	Ø48 * 2.5 mm	54	706.5 m²
35 M	17.5 M	11	Ø48 * 2.5 mm	66	961.625 m²
40 M	20 M	12	Ø60 * 3.0 mm	72	1256 m²

Frame	Q235 Steel Frame
Cover Material	1) White color, PVC coated 2) Waterproof, anti-UV, flame-retardant according to DIN 4201, B1/M2, NFPA701 3) 800-950 g/square meter (opaque PVC) 4) 650 G/square meter (translucent PVC)
Optional Accessories	PVC Window Side Walls Glass Window Lining & Curtain Glass Door Units Cover and Side Walls Floor System, Lighting Air Conditioner
Wind Resistance	80~100 km/h
Fixing Solution	Ground Anchor, Expandable Bolt, Weight Plate, etc.
Service Life	More than 15 years
Applicable Temperature Range	-30 degree Celsius ~ +70 degree Celsius
Ground Situation	Grassland, Earth Land, Asphalt, Cement Ground, Marble, etc
Connectors	Hot-dip Galvanized Steel Insert.
Additional Services	1) Provide video guidance for installation. 2) Provide engineering calculations for tent structure’s wind, snow, and seismic resistance. 3) Technical professionals provide on-site installation guidance services.
